LIFTING SYSTEMS RACK AND PINION AND CABLE
Material hoist by means of cable or rack and pinion systems for the construction sector
Machinery for vertical transport of materials with levels defined stops. Versatile, easy to install and use, and including all security systems.
Cable hoists facade
Machinery for lifting loads by cable system.
Very useful for new construction, renovations and finished facades, with or without separation front line.
| Technical characteristics | Load capacity |
| 1000 Kg | |
| Maximum height (m) | 100 |
| Internal dimensions of the car (m) * | 2.1 |
| Lifting speed (m / min) | 27 |
| Mast section height (m) | 1.5 |
| Mast weight (kg) | 13.2 |
| Voltage (v) | 400 |
| Control voltage (v) | 48 |
*Consult other internal dimensions
*Technical data can be modified by the manufacturer updates
Rack and Pinion material hoist for facade
Machinery for lifting loads by rack and pinion system.
Very useful for new construction, renovations and finished facades, with or without façade separation line
| Technical characteristics | Load capacity | ||
| 500 Kg | 1300 Kg | 1500 Kg | |
| Maximum height (m) | up to 150 | ||
| Internal dimensions of the car (m) * | 1.3 x 1.4 | 1.8 x 2.0 | 1.8 x 2.0 |
| Lifting speed (m / min) | 22 | 27 | 27 |
| Elem height. elevation (m) | 1.5 | 1.5 | 1.5 |
| Mast weight (kg) | 50 | 64 | 64 |
| Voltage (v) | 400 | 400 | 400 |
| Control voltage (v) | 48 | 48 | 48 |
*Consult other internal dimensions
*Technical data can be modified by the manufacturer updates
Special rack and pinion hoists for plasterboard / bulky loads
Machinery for lifting loads by rack and pinion system
Specially designed for transport of plasterboard walls or other bulky material
| Technical characteristics | Load capacity |
| 1000 Kg | |
| Maximum height (m) | 100 |
| Internal dimensions of the car (m) * | 2.1 |
| Lifting speed (m / min) | 27 |
| Mast section height (m) | 1.5 |
| Mast weight (kg) | 13.2 |
| Voltage (v) | 400 |
| Control voltage (v) | 48 |
*Consult other internal dimensions
*Technical data can be modified by the manufacturer updates
Hoists for lift shafts and hard to reach places
Machinery for lifting loads..
Specially designed for installation in elevator shafts housing and have access to any location having a removable platform. Very suitable for rehabilitations.
| Technical characteristics | Load capacity |
| 1000 Kg | |
| Maximum height (m) | 100 |
| Internal dimensions of the car (m) * | 2.1 |
| Lifting speed (m / min) | 27 |
| Mast section height (m) | 1.5 |
| Mast weight (kg) | 13.2 |
| Voltage (v) | 400 |
| Control voltage (v) | 48 |
*Consult other internal dimensions
*Technical data can be modified by the manufacturer updates
